| FEATURES | APPLICATIONS |
Freewheeling diodes with fast and soft reverse recovery VCE(sat) with positive temperature coefficient Low switching losses Short circuit ruggedness Zero turn-off tail current from MOSFET Ultra low loss Ease For Paralleling | Inductive heating Welding High frequency switching application Solar and Wind Inverters DC/DC Converters Battery Chargers |
| Type | VCES | IC | VCE(sat) | E(on) | Rth(J-C) | Packages | Circuit |
| Tc=25℃ | Tc=80℃ | Tj=25℃ | Tj=125℃ | ||||
| (V) | (A) | (V) | (mJ) | (K/W) | |||
| DKG50HF120TE | 1200 | 50 | 2.07 | 5.2 | 0.46 | G1 | |
| DKG50HF120TK | 1200 | 50 | 2.4 | 7.5 | 0.84 | G1 | |
| DKG75HF65TK | 650 | 75 | 2 | 1 | 0.41 | G1 | |
| DKG75HF120TE | 1200 | 75 | 1.98 | 2.2 | 0.5 | G1 | |
| DKG 75HF120TK | 1200 | 75 | 2.5 | 9.1 | 0.35 | G1 | |
| DKG100HF65TS | 650 | 100 | 1.56 | 5.2 | 0.26 | G1 | |
| DKG 100HF120TE | 1200 | 100 | 1.98 | 2.3 | 0.25 | G1 | |
| DKG 100HF120TK | 1200 | 100 | 2.7 | 14 | 0.25 | G1 | |
| DKG150HF65TS | 650 | 150 | 1.56 | 15.3 | 0.26 | G1 | |
| DKG 150HF120TE | 1200 | 150 | 2.1 | 15.1 | 0.16 | G2 | |
| DKG 150HF120TK | 1200 | 150 | 2.5 | 20.7 | 0.18 | G2 | |
| DKG200HF65TS | 650 | 200 | 1.6 | 24.6 | 0.22 | G1 | |
| DKG 200HF120TS | 1200 | 200 | 1.6 | 30 | 0.2 | G2 | |
| DKG 200HF120TK | 1200 | 200 | 2.4 | 26.4 | 0.14 | G2 | |
| DKG 300HF120TE | 1200 | 300 | 1.5 | 11.1 | 0.1 | G2 | |
| DKG 300HF120TK | 1200 | 300 | 2.5 | 29.5 | 0.1 | G2 | |
| DKG300HF120TA | 1200 | 300 | 1.6 | 17.3 | 0.12 | G2 | |
| DKG 400HF120TE | 1200 | 400 | 1.69 | 10.9 | 0.07 | G2 | |
| DKG 400HF120TK | 1200 | 400 | 2.2 | 74 | 0.09 | G2 | |
| DKG450HF120TE | 1200 | 450 | 1.5 | 27.1 | 0.08 | G2 | |
| DKG 450HF120TK | 1200 | 450 | 2.5 | 39.6 | 0.07 | G2 | |
| DKG600HF120TE | 1200 | 600 | 2 | 82.2 | 0.07 | G2 | |
| DKG450HF120TA | 1200 | 450 | 1.6 | 38.1 | 0.09 | G8 | |
| DKG600HF120TA | 1200 | 600 | 1.53 | 140 | 0.05 | G8 | |
| DKG900HF120TE | 1200 | 900 | 1.55 | 133.9 | 0.045 | G8 |
